Big Creek, Florence Lake Dam - Arch #21 deflection measurements - Stationary monument from which radial deflections are made.
photCL SCE 02 - 43634
Visual Materials
Big Creek, Florence Lake Dam - Arch 21 deflection measurements. Scafolding erected for arch deflection tests.
photCL SCE 02 - 43638
Visual Materials
Big Creek, Florence Lake Dam - Whitmore strain gage to make rib shortening measurements on arch, also leads from two resistance thermometers grouted into area.
photCL SCE 02 - 43636
Visual Materials
Big Creek, Florence Lake Dam - Making radial deflection measurements with inside micrometer at stationary monument.
photCL SCE 02 - 43635
Visual Materials
Big Creek, Florence Lake Dam - Chipping for downstream surface thermometer resistance on intrados of Arch #6. Elevation 7313, 2 ft. east of center line
photCL SCE 02 - 22864
Visual Materials
Big Creek, Florence Lake Dam - Close-up of thermometer resistances in place on upstream surface of Arch #6 prior to grouting in.
photCL SCE 02 - 22865
