Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Chipping for downstream surface thermometer resistance on intrados of Arch #6. Elevation 7313, 2 ft. east of center line
Type: Visual Materials(Opens in new tab)
Date: Feb. 1940
Call number: photCL SCE 02 - 22864
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
