Big Creek, Florence Lake Dam - Close-up

Description: Big Creek, Florence Lake Dam - Close-up of open seam at junction of angle buttress 10 and Arch 11 at elevation 7288. 1 1/8" barrel reinforcing steel exposed by chipping and cleaning out seam. This seam is directly opposite spurt noted on downstream side during inspection.
Type: Visual Materials(Opens in new tab)
Date: 4/3/1939
Call number: photCL SCE 02 - 22169
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)

You might also be interested in

Big Creek, Florence Lake Dam - Close-up
Visual Materials
Big Creek, Florence Lake Dam - Close-up of a portion of open seam on Arch 9 at elevation 7296 and 10' west of center line showing 3/8" vertical Tie steel exposed after chipping and cleaning out seam.
photCL SCE 02 - 22167
Big Creek, Florence Lake Dam - Close-up
Visual Materials
Big Creek, Florence Lake Dam - Close-up of a portion of open seam on Arch 9 at elevation 7296 and 13' west of center line showing exposed loop of 3/8" reinforcing steel lying in day's work joint. Joint was dug out to approximately 1" in width with a short piece of wire.
photCL SCE 02 - 22168
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - View of open seam on extrados surface of Arch #36 at elevation 7308 and at junction with spillway section. this seam is directly opposite spurt noted on downstream side during intrados inspection.
photCL SCE 02 - 22170
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - View of river section looking N (downstream) from approximately the upstream face of Arch 53, showing heavy reinforcing at junction of Buttresses 53 & 54, with arches 52, 53, & 54 (highest portion of dam), interados form trusses and studding for lower lifts on Arch 54, and counterweighted placing chutes in position for concreting a lift in Buttress 54.
photCL SCE 02 - 12707
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Bad seam in Buttress.
photCL SCE 02 - 12677
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - View of open seam on Arch #36 at elevation 7308 after chipping out and ready for sealing with stiff grout.
photCL SCE 02 - 22171
