Big Creek, Florence Lake Dam - Close-up

Description: Big Creek, Florence Lake Dam - Close-up of a portion of open seam on Arch 9 at elevation 7296 and 13' west of center line showing exposed loop of 3/8" reinforcing steel lying in day's work joint. Joint was dug out to approximately 1" in width with a short piece of wire.
Type: Visual Materials(Opens in new tab)
Date: 4/3/1939
Call number: photCL SCE 02 - 22168
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
