Big Creek, Florence Lake Dam - Close-up

Description: Big Creek, Florence Lake Dam - Close-up of open seam of extrados surface Arch 9 at elevation 7296 near crown of arch.
Type: Visual Materials(Opens in new tab)
Date: 4/3/1939
Call number: photCL SCE 02 - 22165
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
