Big Creek, Florence Lake Dam

You might also be interested in

•

  Big Creek, Florence Lake Dam

  Visual Materials

  Big Creek, Florence Lake Dam - Day's Work Joint Repair April 1940. No. 7 of cycle of 7: Final view of seam after guniting.

  photCL SCE 02 - 22885

•

  Big Creek, Florence Lake Dam - Day's Work Joint Repair April 1940

  Visual Materials

  Big Creek, Florence Lake Dam - Day's Work Joint Repair April 1940. No. 5 of cycle of 7: Close-up of chipped joint with caulking compound in place ready for guniting.

  photCL SCE 02 - 22883

•

  Big Creek, Florence Lake Dam

  Visual Materials

  Big Creek, Florence Lake Dam - Day's Work Joint Repair April 1940. No. 3 of cycle of 7: Joint completely chipped and ready for Dock Coating caulking compound along the joint.

  photCL SCE 02 - 22881

•

  Big Creek, Florence Lake Dam

  Visual Materials

  Big Creek, Florence Lake Dam - Day's Work Joint Repair April 1940. No. 4 of cycle of 7: Applying a caulking bead of dock coating compound with an Alemite gun directly to exposed joint at bottom of key.

  photCL SCE 02 - 22882

•

  Big Creek, Florence Lake Dam - Close-up

  Visual Materials

  Big Creek, Florence Lake Dam - Close-up of a portion of open seam on Arch 9 at elevation 7296 and 13' west of center line showing exposed loop of 3/8" reinforcing steel lying in day's work joint. Joint was dug out to approximately 1" in width with a short piece of wire.

  photCL SCE 02 - 22168

•

  Big Creek, Florence Lake Dam

  Visual Materials

  Big Creek, Florence Lake Dam - Spurt through open day's work joint 1' from haunch, Buttress #36 in Arch #36, Elevation 7304.

  photCL SCE 02 - 22118
