Big Creek, Florence Lake Dam - Day's Work Joint Repair April 1940

Description: Big Creek, Florence Lake Dam - Day's Work Joint Repair April 1940. No. 5 of cycle of 7: Close-up of chipped joint with caulking compound in place ready for guniting.
Type: Visual Materials(Opens in new tab)
Date: 4/27/1940
Call number: photCL SCE 02 - 22883
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
