Big Creek, Florence Lake Dam - Day's Work Joint Repair April 1940

Description: Big Creek, Florence Lake Dam - Day's Work Joint Repair April 1940. No. 2 of cycle of 7: Chipping out seam. At the moment he is bush-hammering marginal area around the direct key over joint.
Type: Visual Materials(Opens in new tab)
Date: 4/25/1940
Call number: photCL SCE 02 - 22880
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
