Big Creek, Florence Lake Dam - Arch #21 deflection measurements

Description
Big Creek, Florence Lake Dam - Arch #21 deflection measurements - Stationary monument from which radial deflections are made.
Type
Visual Materials(Opens in new tab)
Date
8/17/1955
Call number
photCL SCE 02 - 43634
