Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Arch 21 deflection measurements. Scafolding erected for arch deflection tests.
Type: Visual Materials(Opens in new tab)
Date: 8/17/1955
Call number: photCL SCE 02 - 43638
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
