Visual Materials

Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Whitmore strain gage to make rib shortening measurements on arch, also leads from two resistance thermometers grouted into area.
Type: Visual Materials(Opens in new tab)
Date: 8/17/1955
Call number: photCL SCE 02 - 43636
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
