Big Creek, Florence Lake Dam

Description
Big Creek, Florence Lake Dam - One of the four 1.5" diameter drains through the arch approximately 1' above the lower horizontal key before covering with facing steel. Pipes were sulfured and grouted in. 1.5" iron stop cocks were placed on the downstream ends of the pipes.
Type
Visual Materials(Opens in new tab)
Date
5/20/1942
Call number
photCL SCE 02 - 24703
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)

You might also be interested in

  • Big Creek, Florence Lake Dam

    Big Creek, Florence Lake Dam

    Visual Materials

    Big Creek, Florence Lake Dam - Close-up of 9" sealing plate in lower horizontal key after guniting in place. Plate is imbedded 6.5" in gunite. The 12' lengths of plate were electrically butt welded at the ends before guniting.

    photCL SCE 02 - 24702

  • Big Creek, Florence Lake Dam

    Big Creek, Florence Lake Dam

    Visual Materials

    Big Creek, Florence Lake Dam - Arch #13, Guniting upper horizontal key.

    photCL SCE 02 - 24714

  • Big Creek, Florence Lake Dam

    Big Creek, Florence Lake Dam

    Visual Materials

    Big Creek, Florence Lake Dam - Close-up of 9" sealing plate, and reinforcing mesh in place in lower horizontal key prior to guniting Arch 13.

    photCL SCE 02 - 24701

  • Big Creek, Florence Lake Dam - Arch #13

    Big Creek, Florence Lake Dam - Arch #13

    Visual Materials

    Big Creek, Florence Lake Dam - Arch #13 - Showing top course of sheets bent over in upper horizontal key at edge of walkway.

    photCL SCE 02 - 24713

  • Big Creek, Florence Lake Dam

    Big Creek, Florence Lake Dam

    Visual Materials

    Big Creek, Florence Lake Dam - Whitmore strain gage to make rib shortening measurements on arch, also leads from two resistance thermometers grouted into area.

    photCL SCE 02 - 43636

  • Big Creek General - Florence Lake Dam

    Big Creek General - Florence Lake Dam

    Visual Materials

    Big Creek General - Florence Lake Dam - typical grouted joint repair A.B.49

    photCL SCE 02 - 28159
