Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Close-up of groin between Arch 13 & 14, showing 24" sealing plate imbedded in gunite filler.
photCL SCE 02 - 24199
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Close-up of 9" sealing plate, and reinforcing mesh in place in lower horizontal key prior to guniting Arch 13.
photCL SCE 02 - 24701
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Arch #13 Close-up of side seals. The exposed portion of the 24" steel plates imbedded 12" in the groin gunite was bent over the ends of the courses of face steel and welded.
photCL SCE 02 - 24707
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Arch #13, Guniting upper horizontal key.
photCL SCE 02 - 24714
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Arch #13 Covered with welded steel plate.
photCL SCE 02 - 24635
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - View of open seam on Arch #36 at elevation 7308 after chipping out and ready for sealing with stiff grout.
photCL SCE 02 - 22171
