Big Creek, Florence Lake Dam

Description
Big Creek, Florence Lake Dam - Arch #13 Close-up of side seals. The exposed portion of the 24" steel plates imbedded 12" in the groin gunite was bent over the ends of the courses of face steel and welded.
Type
Visual Materials(Opens in new tab)
Date
6/1/1942
Call number
photCL SCE 02 - 24707
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)

You might also be interested in

  • Big Creek, Florence Lake Dam

    Big Creek, Florence Lake Dam

    Visual Materials

    Big Creek, Florence Lake Dam - Close-up of 9" sealing plate in lower horizontal key after guniting in place. Plate is imbedded 6.5" in gunite. The 12' lengths of plate were electrically butt welded at the ends before guniting.

    photCL SCE 02 - 24702

  • Big Creek, Florence Lake Dam

    Big Creek, Florence Lake Dam

    Visual Materials

    Big Creek, Florence Lake Dam - Close-up of groin between Arch 13 & 14, showing 24" sealing plate imbedded in gunite filler.

    photCL SCE 02 - 24199

  • Big Creek, Florence Lake Dam

    Big Creek, Florence Lake Dam

    Visual Materials

    Big Creek, Florence Lake Dam - Arch #13 Showing operation of bending 24" vertical steel in groin with use of truck jack and maul. All sheets were bent cold.

    photCL SCE 02 - 24708

  • Big Creek, Florence Lake Dam

    Big Creek, Florence Lake Dam

    Visual Materials

    Big Creek, Florence Lake Dam - Typical blister formed under asbestile waterproofing on arch 12 side of gunite fillet in Arch 12-13 groin while subjecting Arch 13 to 3/4 lb. air pressure for testing leaks.

    photCL SCE 02 - 24878

  • Big Creek, Florence Lake Dam

    Big Creek, Florence Lake Dam

    Visual Materials

    Big Creek, Florence Lake Dam - Arch #13 Covered with welded steel plate.

    photCL SCE 02 - 24635

  • Big Creek, Florence Lake Dam

    Big Creek, Florence Lake Dam

    Visual Materials

    Big Creek, Florence Lake Dam - Gunite checking upstream face of spillway.

    photCL SCE 02 - 23973
