Big Creek, Florence Lake Dam - Close-up

Description: Big Creek, Florence Lake Dam - Close-up of thermometer resistances in place on upstream surface of Arch #6 prior to grouting in.
Type: Visual Materials(Opens in new tab)
Date: Feb. 1940
Call number: photCL SCE 02 - 22865
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
