Visual Materials

Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Arch #13, Welding face plates. Installation of steel facing on arch.
Type: Visual Materials(Opens in new tab)
Date: 6/6/1942
Call number: photCL SCE 02 - 24715
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
