Visual Materials
Big Creek, Florence Lake Dam - Arch #13 progress picture showing installation of steel facing. Ironhide prime coat and 1st. coat of aluminum reflecting coat over lower portion. .
photCL SCE 02 - 24706
Visual Materials
Big Creek, Florence Lake Dam - Extrados of Arch #13 after all chipping and scaling of loose and disintegrated concrete was completed in preparation for the installation of steel facing.
photCL SCE 02 - 24198
Visual Materials
Big Creek, Florence Lake Dam - Arch #13 Skylining 5'x8' sheets from ground to scaffold. Steel facing on arch.
photCL SCE 02 - 24709
Visual Materials
Big Creek, Florence Lake Dam - One of the four 1.5" diameter drains through the arch approximately 1' above the lower horizontal key before covering with facing steel. Pipes were sulfured and grouted in. 1.5" iron stop cocks were placed on the downstream ends of the pipes.
photCL SCE 02 - 24703
Visual Materials
Big Creek, Florence Lake Dam - Arch #13 - Placing sheets on anchor bolts. Steel facing on arch.
photCL SCE 02 - 24711
Visual Materials
Big Creek, Florence Lake Dam - Arch #13 Close-up of lower horizontal seal completed.
photCL SCE 02 - 24704
