Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Arch #13 progress picture showing installation of steel facing. Ironhide prime coat and 1st. coat of aluminum reflecting coat over lower portion. .
Type: Visual Materials(Opens in new tab)
Date: 5/31/1942
Call number: photCL SCE 02 - 24706
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
