Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - View of portion of Arch 8 showing area where Johns-Manville waterpoofing has torn loose from arch. This area was repaired during June 1942, by sealing exposed day's work joints and margins with asbestile waterproofing and covering with reflecting coat of aluminum.
