Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Record photo of River Section arches. Johns-Manville waterproofing on all arches except Arch No. 53. Upper portion of Arch 53 is covered with Barrett Waterworks enamel. The lower portion is linseed oil treatment over gunite with reflective coating of aluminum.
Type: Visual Materials(Opens in new tab)
Date: 1/1/1943
Call number: photCL SCE 02 - 24838
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
