Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Record photo of Arches 50, 51, and 52 after completion of Johns-Manville waterproofing.
Type: Visual Materials(Opens in new tab)
Date: 1/1/1943
Call number: photCL SCE 02 - 24835
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
