Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Progress photo showing application of Johns-Manville Waterproofing to final lift on Arch No. 52.
Type: Visual Materials(Opens in new tab)
Date: 12/11/1942
Call number: photCL SCE 02 - 24821
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
