Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Close-up showing application of 15# felt and final coat of plastic on Arch No. 52. Johns-Manville waterproofing being applied by the J.H. Bryant Co.
Type: Visual Materials(Opens in new tab)
Date: 12/11/1942
Call number: photCL SCE 02 - 24820a
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
