Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Extrados of Arch #13 after all chipping and scaling of loose and disintegrated concrete was completed in preparation for the installation of steel facing.
Type: Visual Materials(Opens in new tab)
Date: 5/8/1942
Call number: photCL SCE 02 - 24198
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
