Big Creek, Florence Lake Dam - View showing details of shop-built, panel

Description
Big Creek, Florence Lake Dam - View showing details of shop-built, panel-type extrados forms, and built-in-place intrados forms on Arches 13 &14; also forms for Buttresses 12, 13 &14. [Intrados reinforcing steel has been placed for Arch 13. Buttress head reinforcing also shown for junction between Arches 13-14 and 14-15.]
Type
Visual Materials(Opens in new tab)
Date
7/1/1925
Call number
photCL SCE 02 - 12660
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
