Big Creek, Florence Lake Dam - First two Arches & Buttresses at Florence Lake Dam

Description: Big Creek, Florence Lake Dam - First two Arches & Buttresses at Florence Lake Dam - West section view looking north towards arches 13, & 14; showing concrete placed during early Spring to elevation approx. 7230', salvaged rail from florence tunnel which was used for heavy cantilever reinforcing, extrados panel forms, tramway trestle in background, the concrete mixing plant which served the west portion of the dam, and the west section chuting tower.
Type: Visual Materials(Opens in new tab)
Date: 5/21/1925
Call number: photCL SCE 02 - 12557
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)

Big Creek, Florence Lake Dam

Visual Materials

Big Creek, Florence Lake Dam - View looking North showing erection of forms for construction above early spring work on Arches 13 & 14, excavation for Arch 15, tramway trestle, West mixing plant, and West chuting towers in background, interados forms being erected for Arch 13, and concrete placing for Buttress 12 in progress.

photCL SCE 02 - 12646

Big Creek, Florence Lake Dam

Visual Materials

Big Creek, Florence Lake Dam - View from about 500 feet upstream and looking N, showing plant and construction for river section of dam. (The derrick shown in the center foreground was used for handling all heavy construction material, particularly gates and racks. The East or river section chuting tower and mixing plant are at left center. Top of west chuting tower and mast for aggregate plant derrick can be seen in background. Angle buttress 49 shown to left of mixing plant.

photCL SCE 02 - 12734

Big Creek, Florence Lake Dam - Building forms for Arches

Visual Materials

Big Creek, Florence Lake Dam - Building forms [for Arches] - River Section. [View along line of Arches while concrete is being chuted into forms]

photCL SCE 02 - 12752

Big Creek, Florence Lake Dam - View toward "Frog Pond Section" looking East across buttresses 12 to 18, showing forms in place and concrete placing for buttress 11

Visual Materials

Big Creek, Florence Lake Dam - View toward "Frog Pond Section" looking East across buttresses 12 to 18, showing forms in place and concrete placing for buttress 11. [Tramway trestle, mixing plant and chuting tower are shown in left foreground. The large building shown beyond the end of the trestle is a cement storage warehouse used to store cement for spring work in 1926, before roads were open for transportation. A "lift" of buttress panel forms is being placed on buttress 12 in foreground. Variable-span sectional trusses for supporting interados from sheathing shown at lower right.]

photCL SCE 02 - 12615

Big Creek, Florence Lake Dam

Visual Materials

Big Creek, Florence Lake Dam - Looking west along Arches in River Section towards Mixer Plant.

photCL SCE 02 - 12764

Big Creek, Florence Lake Dam - Middle section

Visual Materials

Big Creek, Florence Lake Dam - Middle section - View of site of west portion of middle section of dam, looking northwest from near the spillway location. (Concrete testing laboratory, machine and compressor shop, and cement warehouse are shown in background. Excavation for Arch and Buttress foundation is shown in progress; also first buttress form. Tramway is shown between excavation and buildings.

photCL SCE 02 - 12855
