Big Creek, Florence Lake Dam - Building forms for Arches

Description
Big Creek, Florence Lake Dam - Building forms [for Arches] - River Section. [View along line of Arches while concrete is being chuted into forms]
Type
Visual Materials(Opens in new tab)
Date
9/1/1925
Call number
photCL SCE 02 - 12752
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
