Big Creek, Florence Lake Dam - Building forms for Arches

Description: Big Creek, Florence Lake Dam - Building forms [for Arches] - River Section.
Type: Visual Materials(Opens in new tab)
Date: 9/1/1925
Call number: photCL SCE 02 - 12750
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
