Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - View of upstream side of river section arches showing plant layout and forms for west sluice gate extension.
Type: Visual Materials(Opens in new tab)
Date: 5/5/1942
Call number: photCL SCE 02 - 24727
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
