Big Creek, Florence Lake Dam
- Description
- Big Creek, Florence Lake Dam - Looking west along Arches in River Section towards Mixer Plant.
- Date
- 9/1/1925
- Call number
- photCL SCE 02 - 12764
Visual Materials
Daily: 10 A.M.–5 P.M.
Closed on Tuesdays
1151 Oxford Road
San Marino, CA 91108
Visual Materials
Big Creek, Florence Lake Dam - First two Arches & Buttresses at Florence Lake Dam - West section view looking north towards arches 13, & 14; showing concrete placed during early Spring to elevation approx. 7230', salvaged rail from florence tunnel which was used for heavy cantilever reinforcing, extrados panel forms, tramway trestle in background, the concrete mixing plant which served the west portion of the dam, and the west section chuting tower.
photCL SCE 02 - 12557
Visual Materials
Big Creek, Florence Lake Dam - River Section, Florence Lake Dam - looking upstream - showing Mixer Plant on right.
photCL SCE 02 - 12793
Visual Materials
Big Creek, Florence Lake Dam - Looking underneath arches of river section.
photCL SCE 02 - 14004
Visual Materials
Big Creek, Florence Lake Dam - Looking underneath arches of river section.
photCL SCE 02 - 14005
Visual Materials
Big Creek, Florence Lake Dam - View of upstream side of river section arches showing plant layout and forms for west sluice gate extension.
photCL SCE 02 - 24727
Visual Materials
Big Creek, Florence Lake Dam - Looking upstream underneath arches of river section.
photCL SCE 02 - 14006
