Portal Powerhouse

Description
Portal Powerhouse - 12' diameter pipe installed to reduce pressure at portal during high flows. At time, the lower baffle was still there at outlet restricting end area.
Type
Visual Materials(Opens in new tab)
Date
11/16/1955
Call number
photCL SCE 02 - 43917
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)

You might also be interested in

  • Portal Powerhouse

    Portal Powerhouse

    Visual Materials

    Portal Powerhouse - View of 8.5' diameter penstock pipe supports inside 12' diameter outlet pipe, Ward Tunnel.

    photCL SCE 02 - 43560

  • Portal Powerhouse

    Portal Powerhouse

    Visual Materials

    Portal Powerhouse - Installing backing I-beams (15") prior to forming for concrete. Strengthening to reduce vibration during high flows.

    photCL SCE 02 - 43902

  • Portal Powerhouse

    Portal Powerhouse

    Visual Materials

    Portal Powerhouse - Side spillway cut to relieve excessive back pressure during high flow. Final baffle now in place at end of penstock.

    photCL SCE 02 - 43928

  • Portal Powerhouse

    Portal Powerhouse

    Visual Materials

    Portal Powerhouse - installation of final design of restrictive baffle at end of by-pass pipe.

    photCL SCE 02 - 43927

  • Portal Powerhouse - Progress picture

    Portal Powerhouse - Progress picture

    Visual Materials

    Portal Powerhouse - Progress picture - First day of outage. Section of 12' diameter outlet pipe cut out and extending skid rails into tunnel for pulling penstock.

    photCL SCE 02 - 44798

  • Portal Powerhouse

    Portal Powerhouse

    Visual Materials

    Portal Powerhouse - Breaking up large boulders in pool at end of 12' diameter pipe.

    photCL SCE 02 - 43325
