Visual Materials

Portal Powerhouse

Description: Portal Powerhouse - Side spillway cut to relieve excessive back pressure during high flow. Final baffle now in place at end of penstock.
Type: Visual Materials(Opens in new tab)
Date: 11/21/1955
Call number: photCL SCE 02 - 43928
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)

You might also be interested in

Portal Powerhouse
Visual Materials
Portal Powerhouse - 400 cfs flow from side channel spillway entering tailrace from new diversion.
photCL SCE 02 - 43961
Portal Powerhouse
Visual Materials
Portal Powerhouse - 12' diameter pipe installed to reduce pressure at portal during high flows. At time, the lower baffle was still there at outlet restricting end area.
photCL SCE 02 - 43917
Portal Powerhouse - Discharge at side
Visual Materials
Portal Powerhouse - Discharge at side - channel spillway at approximately 1500 cfs flow thru tunnel.
photCL SCE 02 - 43918
Portal Powerhouse
Visual Materials
Portal Powerhouse - By-pass pipe after installation of three horizontal baffles. With flow of 1000 cfs, upper two baffles were lost, due to excessive vibration.
photCL SCE 02 - 43916
Portal Powerhouse - Portal Forebay
Visual Materials
Portal Powerhouse - Portal Forebay - Left end of dam from downstream side, showing spillway and pilot channel.
photCL SCE 02 - 43787
Portal Powerhouse - Flow test
Visual Materials
Portal Powerhouse - Flow test - Uncompleted penstock flow approximately 1300 cfs.
photCL SCE 02 - 43876
