Southern California Edison collection of negatives and photographs
Portal Powerhouse

Visual Materials

Portal Powerhouse

Description: Portal Powerhouse - By-pass pipe after installation of three horizontal baffles. With flow of 1000 cfs, upper two baffles were lost, due to excessive vibration.
Type: Visual Materials(Opens in new tab)
Date: 11/12/1955
Call number: photCL SCE 02 - 43916
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
