Borel Powerhouse - Kern River - Borel 3rd stage

Description: Borel Powerhouse - Kern River - Borel 3rd stage - Shows work accomplished on construction of new concrete flume at Tilley #3 prior to canal outage when steel flume can be removed. Concrete piers raised and backfilled for floor slab support with the exception of two center spans which were left open for drainage.
Type: Visual Materials(Opens in new tab)
Date: 10/31/1951
Call number: photCL SCE 02 - 40043
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
