Borel Powerhouse - Borel 3rd Stage - Tilley #3

Description: Borel Powerhouse - Borel 3rd Stage - Tilley #3 - Photos showing dismantlement of steel flume sheets.
Type: Visual Materials(Opens in new tab)
Date: 12/13/1951
Call number: photCL SCE 02 - 40077
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
