Kaweah #1 - Watershed - Mineral King Dams

Description: Kaweah #1 - Watershed - Mineral King Dams - Close-up of a portion of upstream facing directly above intake of 8" discharge pipe. Smaller rocks and evidenly less care was taken in building this portion of masonry wall. [variant of 02-25709a].
Type: Visual Materials(Opens in new tab)
Date: 9/30/1943
Call number: photCL SCE 02 - 25709b
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
