Kaweah #1 - Watershed - Mineral King Dams

Description: Kaweah #1 - Watershed - Mineral King Dams - Upstream view of lower Franklin Dam taken from near north end. Lake approximately 20" below spill elevation.
Type: Visual Materials(Opens in new tab)
Date: 8/4/1943
Call number: photCL SCE 02 - 25702
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)

You might also be interested in

Kaweah #1 - Watershed - Mineral King Dams
Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - Downstream view of lower Franklin Dam taken from near north end. Lake approximately 20" below spill elevation and leakage through dam estimated to be 7 cfs.
photCL SCE 02 - 25701
Kaweah #1 - Watershed - Mineral King Dams
Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - Upstream view of Eagle Dam taken during inspection. Water at spill elevation. Leakage under dam estimated at 1/4 cfs.
photCL SCE 02 - 25705
Kaweah #1 - Watershed - Mineral King Dams
Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - Downstream view of Crystal Dam. Water at spill elevation. Estimated leakage, 1 cfs, most of which is concentrated in lower part of "V" near discharge pipe. .
photCL SCE 02 - 25706
Kaweah #1 - Watershed - Mineral King Dams
Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - View of Monarch Dam taken during inspection. Water at spill elevation and estimated leakage of 1.4 cfs.
photCL SCE 02 - 25710b
Kaweah #1 - Watershed - Mineral King Dams
Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - Close-up view of a top section of the upstream face of lower Franklin Dam taken from near north end, showing the checked and spalled condition of the neat cement plastering over the masonry joints in the face rock.
photCL SCE 02 - 25703
Kaweah #1 - Watershed - Mineral King Dams
Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - progress photo showing chipping and grouting defective masonry joints near the north end of the upstream face of Franklin Dam.
photCL SCE 02 - 25708
