Kaweah #1 - Watershed - Mineral King Dams

Description: Kaweah #1 - Watershed - Mineral King Dams - View of the upstream face of Monarch Dam taken from discharge channel to south east end. Photo taken prior to any work.
Type: Visual Materials(Opens in new tab)
Date: 9/28/1943
Call number: photCL SCE 02 - 25711
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)

You might also be interested in

Kaweah #1 - Watershed - Mineral King Dams
Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - upstream face of Franklin Dam at discharge channel with water at minimum level. A portion of the trash rack can be seen in back of two logs lying in channel. Upper portion of rock face had been repaired prior to this date. .
photCL SCE 02 - 25709a
Kaweah #1 - Watershed - Mineral King Dams
Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - Section of upstream face of Monarch Dam directly above discharge pipe after chipping. Re-grouting joints from scaffold in upper portion of photo.
photCL SCE 02 - 25712
Kaweah #1 - Watershed - Mineral King Dams
Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - Tamping grout in chipped out joint, upstream face of Monarch Dam. Note typical heavy pointing over joints.
photCL SCE 02 - 25713
Kaweah #1 - Watershed - Mineral King Dams
Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - Downstream view of Monarch Dam taken during inspection. .
photCL SCE 02 - 25710a
Kaweah #1 - Watershed - Mineral King Dams
Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - Close-up view of a top section of the upstream face of lower Franklin Dam taken from near north end, showing the checked and spalled condition of the neat cement plastering over the masonry joints in the face rock.
photCL SCE 02 - 25703
Kaweah #1 - Watershed - Mineral King Dams
Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - Close-up of a portion of upstream facing directly above intake of 8" discharge pipe. Smaller rocks and evidenly less care was taken in building this portion of masonry wall. [variant of 02-25709a].
photCL SCE 02 - 25709b
