Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - progress photo showing chipping and grouting defective masonry joints near the north end of the upstream face of Franklin Dam.
photCL SCE 02 - 25708
Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - Tamping grout in chipped out joint, upstream face of Monarch Dam. Note typical heavy pointing over joints.
photCL SCE 02 - 25713
Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - View of the upstream face of Monarch Dam taken from discharge channel to south east end. Photo taken prior to any work.
photCL SCE 02 - 25711
Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - Upstream view near north end of Franklin Dam showing the process of chipping out defective masonry joints with syntron electric hammer. Note the amount of cracks to right of operator, ready for refilling with hand tamped grout.
photCL SCE 02 - 25707a
Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - Close-up view of a top section of the upstream face of lower Franklin Dam taken from near north end, showing the checked and spalled condition of the neat cement plastering over the masonry joints in the face rock.
photCL SCE 02 - 25703
Visual Materials
Kaweah #1 - Watershed - Mineral King Dams - Close-up of a portion of the area shown in previous shot showing typical joints opened up for re-grouting. Mortar extended in approximately 4" from face of rocks. In back of mortar, rocks were imbedded in earth. [variant of 02-25707a].
photCL SCE 02 - 25707b
