Kaweah #1 - Watershed - Mineral King Dams

Description: Kaweah #1 - Watershed - Mineral King Dams - Upstream view near north end of Franklin Dam showing the process of chipping out defective masonry joints with syntron electric hammer. Note the amount of cracks to right of operator, ready for refilling with hand tamped grout.
Type: Visual Materials(Opens in new tab)
Date: 9/10/1943
Call number: photCL SCE 02 - 25707a
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
