Kaweah #2

Description: Kaweah #2 - 2 Flume - View of re-lining. Asphalt roofing paper and batts in place, but before final spray coat of emulsion. .
Type: Visual Materials(Opens in new tab)
Date: 2/22/1942
Call number: photCL SCE 02 - 24808
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
