Kaweah #2

Description
Kaweah #2 - 2 Flume - Close-up showing space between boards on side of flume. This condition made it necessary to leave steel sheets in place to support asphalt paper and emulsion re-lining.
Type
Visual Materials(Opens in new tab)
Date
2/22/1942
Call number
photCL SCE 02 - 24805
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
