Kaweah No. 2 - Flume

Description
Kaweah No. 2 - Flume - Record photo showing test sheets painted with varying coats of Bitumastic #50 and Asphalt Emulsion, placed on the floor and part of sidewall. Near upper end of flume section No. 1.
Type
Visual Materials(Opens in new tab)
Date
2/22/1942
Call number
photCL SCE 02 - 24133
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
