Visual Materials

Kaweah #2 - #2 Flume

Description: Kaweah #2 - #2 Flume - Applying final spray coat of emulsion over roofing paper in place. .
Type: Visual Materials(Opens in new tab)
Date: 2/22/1942
Call number: photCL SCE 02 - 24809
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
