Kaweah #2

Description: Kaweah #2 - 2 Flume - Close-up of floor after brushing rust and scale off of old steel sheet lining. Note rust holes through lining.
Type: Visual Materials(Opens in new tab)
Date: 2/22/1942
Call number: photCL SCE 02 - 24807
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)

You might also be interested in

Kaweah #2
Visual Materials
Kaweah #2 - Close-up inside Flume showing typical condition found in corner at junction of floor and side wall. Advanced pitting has extended through metal lining at center of bend. In general these holes are covered with rust scale and silt and not noticeable under casual inspection. Picture taken on section No. 1 near intake.
photCL SCE 02 - 24131
Kaweah #2
Visual Materials
Kaweah #2 - Flume close-up showing leakage through flume. This is typical of many places where the metal lining has rusted through at the junction of floor and side wall.
photCL SCE 02 - 24132
Kaweah #2
Visual Materials
Kaweah #2 - 2 Flume - Close-up showing space between boards on side of flume. This condition made it necessary to leave steel sheets in place to support asphalt paper and emulsion re-lining.
photCL SCE 02 - 24805
Kaweah #2
Visual Materials
Kaweah #2 - 2 Flume - View of re-lining. Asphalt roofing paper and batts in place, but before final spray coat of emulsion. .
photCL SCE 02 - 24808
Kaweah #2
Visual Materials
Kaweah #2 - new footings for steel replacement of flume #6
photCL SCE 02 - 28382
Kaweah #2 - Flume #13
Visual Materials
Kaweah #2 - Flume #13 - Support Steel.
photCL SCE 02 - 26864
