Kaweah #2

Description
Kaweah #2 - Close-up inside Flume showing typical condition found in corner at junction of floor and side wall. Advanced pitting has extended through metal lining at center of bend. In general these holes are covered with rust scale and silt and not noticeable under casual inspection. Picture taken on section No. 1 near intake.
Type
Visual Materials(Opens in new tab)
Date
2/22/1942
Call number
photCL SCE 02 - 24131
