Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Close-up of striations caused by ice on surface of J-M waterproofing on Arch 54 near 54-55 groin. This waterproofing was applied in Dec. 42.
Type: Visual Materials(Opens in new tab)
Date: 3/29/1943
Call number: photCL SCE 02 - 24748
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)

You might also be interested in

Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Typical blister formed under asbestile waterproofing on arch 12 side of gunite fillet in Arch 12-13 groin while subjecting Arch 13 to 3/4 lb. air pressure for testing leaks.
photCL SCE 02 - 24878
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Close-up of a cluster of blisters on the J-M Asbestile waterproofing on Arch 8. Waterproofing was applied May 1940.
photCL SCE 02 - 24747
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - View of excavation in groin between Arches 53 & 54 preparatory to guniting Arch 54 up to elevation 7235.
photCL SCE 02 - 24718
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Close-up showing application of 15# felt and final coat of plastic on Arch No. 52. Johns-Manville waterproofing being applied by the J.H. Bryant Co.
photCL SCE 02 - 24820a
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Close-up showing application of 15# felt and final coat of plastic on Arch No. 52. Johns-Manville waterproofing being applied by the J.H. Bryant Co. [variant of 02-24820a].
photCL SCE 02 - 24820b
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Close-up of original surface of arch underneath gunite near crown of Arch #20. Note black surface of original Intertol waterproofing. White area in center of Intertol surface chipped down to sound concrete. Disintegrated layer is approximately 1/4" in depth.
photCL SCE 02 - 24135
