Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - View of excavation in groin between Arches 53 & 54 preparatory to guniting Arch 54 up to elevation 7235.
Type: Visual Materials(Opens in new tab)
Date: 3/28/1942
Call number: photCL SCE 02 - 24718
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
