Big Creek, Florence Lake Dam

Description
Big Creek, Florence Lake Dam - Extrados of Arch No. 52. Taken during guniting operations on this arch. Gunited to elevation 7235 and chipped to elevation 7296.
Type
Visual Materials(Opens in new tab)
Date
5/5/1942
Call number
photCL SCE 02 - 24191
