Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Extrados of Arch No. 52. Taken during guniting operations on this arch. Gunited to elevation 7235 and chipped to elevation 7296.
photCL SCE 02 - 24191
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Method of waterproofing day's work joints on Arch 52, before guniting. 6" strips of asphalt impregnated felt was tacked to the arch between two applications of asbestile waterproofing.
photCL SCE 02 - 24724
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Progress photo showing chipping on Arch 52 completed to elevation 7264, preparatory to guniting.
photCL SCE 02 - 24719
Big Creek, Florence Lake Dam - Close-up
Visual Materials
Big Creek, Florence Lake Dam - Close-up of guniting extrados of Arch #2. Dock coating was applied to days work joints prior to laying galvanized mesh.
photCL SCE 02 - 22887
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Day's Work Joint Repair April 1940. Guniting on Arch 13 and chipping on Arch 14.
photCL SCE 02 - 22876
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Day's Work Joint Repair April 1940. Arch #51 after guniting.
photCL SCE 02 - 22877
